EC > GATE 2026 > Smith Chart
A complex load (in Ω) is represented as ΓL = 0.5∠30° on the Smith chart.
A co-axial cable with a characteristic impedance of 50 Ω is connected to the load.
The new input impedance of the load now moves to a diametrically opposite point on the same Γ circle on the Smith chart.
Which option is the nearest input impedance of the cable connected load (in Ω)?
A co-axial cable with a characteristic impedance of 50 Ω is connected to the load.
The new input impedance of the load now moves to a diametrically opposite point on the same Γ circle on the Smith chart.
Which option is the nearest input impedance of the cable connected load (in Ω)?
Correct :
